E6 Water cooled mid-drive motor

JINYUXING
The world's leading electric light vehicle motor expert

Product parameters:

工作電壓（V）Working voltage 48-72: 48-72

額定功率（W）Rated power 4000-6000: 4000-6000

峰值功率（W）Peak power 5000-10000: 5000-10000

額定轉速（rpm）Rated speed 5000-7000: 5000-7000

峰值扭矩（N.m）Peak torque 25-60: 25-60

峰值效率（%）Peak efficiency ≥90%: ≥90%

防護等級（IP）Protection level 67: 67

絕緣等級 Insulation level H: H

傳感器類型 Sensor type 絕對值磁編碼Absolute value magnetic encoder: 絕對值磁編碼

Working voltage （V）: 48-72

Rated power （W）: 4000-6000

Peak power （W）: 5000-10000

Rated speed （rpm）: 5000-7000

Peak torque （N.m）: 25-60

Peak efficiency （%）: ≥90%

Protection level （IP）: 67

Insulation level: H

Sensor type: Absolute value magnetic encoder

Product size:

安裝孔直徑: 3-Φ8

軸端外徑: Φ16.5(0.，-0.05）

內花鍵參數: INT 9z*1m*20R

軸端至端蓋高度: 12

輪廓最大外直徑: Φ160

輪廓最大高度: 196.7

Installation hole diameter: 3-Φ8

Outer diameter of shaft end: Φ16.5(0.，-0.05）

Internal spline parameters: INT 9z*1m*20R

Height from shaft end to end cover: 12

Maximum outer diameter of contour: Φ160

Maximum height of the profile: 196.7
